Never be caught with an incorrectly sized or missing trailer hitch ball again. From Weigh Safe, the 180° Drop Hitch includes a signature “combination” hitch ball that can be flipped for 2″ or 2-5/16″ applications. The unique design features all the telltale features that Weigh Safe has come to be known. Aluminum and stainless steel construction create a drop hitch (or rise) that is tough, durable and rust-resistant – all while saving weight.
Specifications:
2″ Receiver size (shank)
Max gross trailer weight (all models):
7500 lbs with 1-7/8” ball
8000 lbs with 2” ball
12,500 lbs with 2-5/16” ball
Max tongue weight (all models):
1500 lbs
V5 & J684 certified
Drop hitch adjustment:1″ increments
Ball material: chrome-plated steel
Pin:Dual pin with key lock assembly (included)
Rise:All hitches may be used in rise position
Gain 1 inch (e.g., 4” drops are 5” rises)
Total Height:Add 3 inches (e.g., 4” drops measure 7″ from the top of the receiver to the hitch base)
Includes:
Drawbar
180° Slider
Combo 2″ and 2-5/16″ ball (chrome-plated steel)
Ball retaining pin (1)
Lock plate key assembly
Dust lock cover
Barrel style keys (2)
Optional locking hitch pin Part WS05 (keyed to match locking plate; select models)
Features:
Premium drop hitch with 2″ and 2-5/16″ “combo” hitch ball
6061 T6 billet aluminum shank and mounting platform provide superior strength and durability
Solid block construction provides greater strength than hollow steel competitors
