PISTON KIT 73-81 TS250 72.00, FORGED WOSSNER 8204D200

Sale!
PISTON KIT 73-81 TS250 72.00, FORGED WOSSNER 8204D200

PISTON KIT 73-81 TS250 72.00, FORGED WOSSNER 8204D200

Original price was: $172.00.Current price is: $97.97.

56 in stock

SKU: 56-W249.200.WO Category:

Description

Piston Kit 72.00mm Bore 71.94 Wossner 8204D200 (+2.00)

SUZUKI
TS250 1973-1981,

  • Wossner forged pistons are superior in strength and design.
  • Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
  • Elliptically designed to provide a moreuniformbearingsurface underpiston heat expansion, eliminatinglocalized pressureanddistributingthrust loads moreevenly,therebypreventing pistoncollapse.
  • Made in Germany

Part No. 56-W249.200.WO(oro2u.com)
Lock P/N CW18
Pin P/N WP033
Ring Set P/N RSB7200 x 2

Display (cm3) 249
Hub stroke (mm) 64.00
Clearance (mm) 0.06
Wossner compression Ratio: 2 stroke
OEM Compression ratio: 2 stroke
Dome volume (cm3)
Compression height (mm) 34.00
Theorectical weight (G)
